Within You Without You

Story Section status: Outdated

Recording

Equipment Section status: Outdated

Recording Timeline

• Wednesday 15 March 1967 — Studio Two, 7.00pm–1.30am: ‘Untitled’, take 1. P: George Martin. E: Geoff Emerick. 2E: Richard Lush.¹ The take ran 6'25", with an unrecorded Indian friend on tabla and other session men playing; the outside musicians came from the Asian Music Circle in Fitzalan Road, Finchley.¹ Booking a session under a working title of ‘Untitled’ is a small piece of evidence about how finished the piece was on arrival: the paperwork had nothing to call it, and the tape ran a minute and a half longer than the released record.
• Wednesday 22 March 1967 — Studio Two, 7.00pm–2.15am: superimposition onto take 1, reduction of take 1 into take 2, mono remix 1 from take 2. P: George Martin. E: Geoff Emerick. 2E: Richard Lush.¹ The night also ran the tape off standard speed at 41¼ and at 52½ cycles per second, giving material that plays back very fast in the first case and slowed down in the second.¹ A reduction and a mono remix on the same night as the overdub means the shape of the record was settled here, three weeks before the strings arrived.
• Monday 3 April 1967 — Studio One, 7.00pm–3.00am: superimposition onto take 2. P: George Martin. E: Geoff Emerick. 2E: Richard Lush.¹ George Martin conducted eight violinists and three cellists: Erich Gruenberg led, Alan Loveday was among the violins, the cellists were Reginald Kilbey, Allen Ford and Peter Beavan, and Gruenberg received £11.¹ An eight-hour booking in the orchestral room for one overdub is a large commitment to a part that had to be written to fit an existing tape rather than the other way round.
• Monday 3 April 1967 — Studio Two control room, 3.00–6.30am: mono mixing.¹ Mono remixes 1–3 were made from Part 1 of take 2 and remixes 4 and 5 from Parts 2 and 3.¹ Moving from the orchestral floor to the control room at three in the morning and mixing until half past six is the practical face of an album being finished to a deadline — the strings were mixed the same night they were played, before anyone could hear them fresh.
• Tuesday 4 April 1967 — Studio Two control room, 7.00pm–12.45am: mono and stereo mixing, editing. P: George Martin. E: Geoff Emerick. 2E: Richard Lush.¹ Mono remixes 6–11 came from Part 1 and remix 12 from Parts 2 and 3; the stereo was remixed 1–3 from Part 1 and 4 and 5 from Parts 2 and 3, then edited together from stereo remixes 3 and 5 with a superimposition.¹ At George's request a few seconds of laughter was edited onto the end.¹
• Thursday 1 June 1967 — released on Sgt. Pepper's Lonely Hearts Club Band.¹ The song is the eighth title in the album's running order, following ‘Being For The Benefit Of Mr Kite!’, and it is the longest track on the record.¹

Studio Notes

• What a dilruba brings that a violin cannot — the instruments taken through these sessions were swordmandel, dilruba, tabla, a bowl and a tamboura.¹ A dilruba is bowed like a violin but carries a set of sympathetic strings running under the playing strings, tuned to the notes of the scale and never touched. They vibrate on their own whenever a played note matches them, so every phrase drags a faint halo of the mode behind it. That is the sound a Western string section cannot produce at any volume or with any bowing, and it is why the eleven players added later sit inside the texture as reinforcement rather than as the main event. The swordmandel — a small box zither swept rather than picked — does the same job in the opposite direction, adding a bright wash on top of the sustained middle.
• The drone is the arrangement's foundation, and it was handed to an assistant — the tamboura was played by Beatles assistant Neil Aspinall.¹ A tamboura has a curved bridge that makes each string buzz across a wide spread of overtones, so it fills the space between the other instruments rather than occupying a pitch of its own. It also has to be kept going continuously, which on a six-minute take is an endurance task rather than a musical one. Giving it to a non-musician who was in the building is entirely rational: the part requires stamina and steadiness, not training, and it is the one element of the arrangement that cannot stop.
• Two numbered takes across three weeks — the song reached take 2 only because take 1 was reduced into it on 22 March, and every later addition was a superimposition onto that.¹ A take number normally counts performances; here it counts tape generations. Nothing on the record was ever played straight through by the full ensemble, which is why the piece has no single moment of collective interaction and why its momentum comes from layering rather than from playing. It is closer in method to the collage on side one than its instrumentation suggests.
• Why the song was mixed in three parts — for mixing purposes the song was divided into three parts, and the mono and stereo remix numbering runs separately for Part 1 and for Parts 2 and 3.¹ On a five-minute piece whose sections have genuinely different textures — voice and drone, then the instrumental passage, then the return — treating them as one mix means every fader move is a compromise across all three. Splitting the tape lets each section be balanced on its own terms and joined at the edit. The cost is that the joins have to be inaudible, which is why the finished stereo is itself an edit of two remixes.¹
• Eleven mixes of Part 1, one of the rest — mono remixes 1–3 and 6–11 were all made from Part 1, while Parts 2 and 3 were covered by remixes 4, 5 and 12.¹ That distribution is the most honest available account of where the difficulty lay. Part 1 is where the voice has to be placed against the drone: too far forward and the texture becomes accompaniment, too far back and the words go. Parts 2 and 3, being largely instrumental, have a right answer that can be found in one pass.
• Vari-speed used in both directions — the machine was run at 41¼ cycles per second and at 52½ cycles per second on 22 March.¹ Below standard speed, a part played slowly comes back fast and high; above it, a part comes back slow and low. Running both on one night means the session was treating tape speed as an instrument in its own right rather than as a fix for something unplayable. It also has a consequence peculiar to this song: Indian instruments are not tuned to equal temperament, so shifting their pitch by a machine does not move them to a wrong note in the way it would move a piano — it moves the whole modal relationship intact, which is why the treatment is far less audible here than the same trick is elsewhere on the album.
• The mixdown itself was run off standard speed — this was one of three tracks on the album mixed with the oscillator set away from the mains frequency.² Changing the frequency feeding the machine changes the capstan speed, so pitch and tempo move together and there is no way to have one without the other. On a record whose released pitch is therefore not the pitch performed, any attempt to play along with it from a written key will be a fraction out, and the discrepancy is a property of the mix rather than of the master.
• A Western string section written to fit a finished tape — eight violinists and three cellists were conducted by George Martin on 3 April, three weeks after the basic track was reduced.¹ Scoring last is the opposite of the usual orchestral procedure, where the players define the harmony and the band fits around them. Here the harmony, the drone and the tempo were already fixed on tape, so the score had to be written against a recording that could not be adjusted, and the players had to match intonation to instruments that are not tuned as theirs are. The restraint that results — long held lines, very little vibrato, almost no independent movement — is a practical consequence of that constraint before it is an aesthetic one.
• The laughter is an edit, not a performance — a few seconds of laughter was edited onto the end at George's request.¹ Because it is spliced on rather than recorded with the ensemble, it carries none of the room the rest of the track was made in, and that acoustic mismatch is exactly what makes it work: it arrives from outside the record. It is also the only element of the arrangement that required no musician, no take number and no mix — a razor blade and a decision.

Releases

Which released versions of “Within You Without You” sound different, and what the listener hears on each.

• 1967 UK mono LP — Sgt. Pepper's Lonely Hearts Club Band (1 June 1967, Parlophone PMC 7027, eighth track) — the mix the record was made for and the one that took eleven passes at its opening section. Everything is centred and layered forward: the drone sits directly under the voice, the dilruba and the strings occupy the same space rather than facing each other, and the laughter at the end arrives close and dry. This is the reference for everything below.
• 1967 UK stereo LP — Sgt. Pepper's Lonely Hearts Club Band (1 June 1967, Parlophone PCS 7027, eighth track) — assembled from two separate remixes joined at an edit, and the seams in the texture are audible as changes of width. The hard split pulls the Indian instruments and the strings apart, which makes the individual lines far easier to follow and the sympathetic ringing of the dilruba much clearer, at the cost of the single blended body the mono presents.
• 2009 stereo remaster — Sgt. Pepper's Lonely Hearts Club Band (9 September 2009, Apple/EMI) — a remaster of the 1967 stereo rather than a remix, so the split and the edit points are unchanged. What improves is depth inside each side: the tamboura separates from the dilruba instead of merging into one buzz, the tabla regains its low resonance, and the cellos stop crowding the middle strings.
• 2009 mono remaster — The Beatles in Mono (9 September 2009, Apple/EMI) — the 1967 mono remastered, and the version to reach for first on this song above almost any other on the album. Denser, closer and considerably more hypnotic than any stereo of it, with the vocal embedded in the drone rather than sitting in front of it.
• 2017 stereo remix — Sgt. Pepper's Lonely Hearts Club Band anniversary edition (2017, Apple, Giles Martin and Sam Okell) — a new mix from the tapes that abandons the hard split and rebuilds the piece around a centred voice and drone, using the width for the string section and the upper instruments. It is the closest a stereo version comes to the mono's sense of a single body of sound, and the tabla is more clearly articulated on it than on any earlier release.

Sources

1. Mark Lewisohn, The Complete Beatles Recording Sessions (New York: Harmony Books, 1988), 103, 104, 107, 200.
2. Kevin Ryan and Brian Kehew, Recording the Beatles: The Studio Equipment and Techniques Used to Create Their Classic Albums (Houston: Curvebender Publishing, 2006), 293–294, and chaps. 3–4 for the Studio One and Studio Two equipment of the period.
